Ton Packing Press Machine (Hydraulic Press)

Ton Packing Press (Hydraulic Press)

Technical Note:

1. Current situation: When the customer's products are loaded into the ton bag, when the double layer is stacked, due to the pressure of the upper ton bag, the lower ton bag is deformed and tilted, causing the upper ton bag to slip.

In order to avoid the above problems, the customer proposed to use a special tonnage bale press, before stacking, the lower tonnage bale was flattened and pressed, and then the upper layer was stacked into the tonnage bale.

Contact Now E-Mail Telephone WhatsApp

Product Details

Operation process of Ton Packing Press Machine (Hydraulic Press):

Manually use a hydraulic trailer to lift the ton bale with a pallet, push it into the limited position under the press pressure plate, and the hydraulic trailer is removed from the working position; Manually open the press, carry out tonnage bale compression, pressure delay 10-20 seconds (this parameter is adjusted according to actual needs), during the pressure delay process, manually hang the tonnage sling strap quickly to the lifting lug, and then the pressure plate automatically lifts (this process is automatic) to lift the sling, the ton bag also rises, rises to a certain position to stop the action, this process realizes bag shaping; The ton bale press starts to press down for the second time, and then performs the ton bale compression again, the pressure delay is 10-20 seconds (this parameter is adjusted according to actual needs), the pressure delay process quickly disengages the sling from the lifting lugs, and then the pressure plate rises again; After the second compression, the whole baling process is over, and the product tonnage package is manually dragged out with a hydraulic trailer and sent to the designated storage location.

Ton Packing Press Machine (Hydraulic Press)

Specifications of Ton Packing Press Machine (Hydraulic Press):

Standard soft ton bag, equipped with chopped glass fiber, weighing about 1000kg; Dimensions when the product is filled: L x W x H = 1100 x 1100 x 1050mm.

Ton Packing Press Machine (Hydraulic Press)

Pallet specifications for lower tonnage bags: wooden, size L x W x H = 1120 x 1120 x 135mm.

Ton Packing Press Machine (Hydraulic Press)

Ton Packing Press Machine (Hydraulic Press) Description:

1. Equipment operation requirements:

1.1 Through the LCD screen, it is convenient to adjust and lock the main common working parameters, and view the main working parameters. Working parameters: pressure, pressing time, number of compressions, pressing speed.

1.2 Install the sling lugs above the pressure plate, which are used to lift up after pressing the ton bag for the first time.

1.3 When the equipment starts, when the pressure plate is rolled down for the first time, hang the sling, the pressure plate rises to lift the ton pack, the pressure plate presses down for the second time, the sling is removed, and the pressure plate rises to complete a working cycle.

2 Main data:

2.1 The pressure of the hydraulic station is adjustable, and the pressure range is 0.5~5 tons (the maximum design pressure is 5 tons);

2.2 The vertical stroke of the pressure plate is designed to be 450mm, in order to ensure the tightness of the pressure plate pressing ton bag and the effect of lifting the ton bag, the pressure plate stroke must be adjustable;

2.3 The pressing time of the pressure plate is adjustable, the operating space is suitable, and the product is pushed into the positioning device.

3. Equipment composition: equipment frame, hydraulic cylinder, pressure plate (installed with 4 hanging lugs), hydraulic station, LCD screen, etc.

4. Equipment function: simple operation, reliable function, beautiful appearance, fully meet the production requirements of the demand side.

5. Hydraulic station: rated pressure: 6.3MPa, cylinder pressure 1-5 tons adjustable

6. Pipeline connection mode: the demand side 4 seamless pipe to the front of the equipment and install the ball valve.

7.Cylinder: fine grinding hydraulic cylinder,

8. Operating procedures: electric control

Ton Packing Press Machine (Hydraulic Press)
