Hot Sales Full Automatic Unmanned Carton Bagging Machine

Introduction of computerized bagging and packaging machine


Automatic bagging packaging machine, additionally acknowledged as reduce packaging machine, is generally a laptop that wraps the product with warmness shrinkable movie and then heats it, so that the movie shrinks and wraps the product. It makes use of warmness shrinkable movie in the heating state, the irregular association between the authentic molecules has changed, below infrared and different warmth radiation, plastic molecules are rearranged tightly, so that the unique place is appreciably reduced, and it is connected to the floor of the product to attain the cause of packaging. During the shrinking manner of the shrinking machine, it does no longer have an effect on the best of the packaging, however can reduce rapidly and perfectly, and the packaged product can be sealed, moisture-proof, impact-proof, appropriate for more than one objects tightly packed and palletized.

  Contact Now E-Mail Telephone WhatsApp
Product Details


Full Automatic Unmanned Carton Bagging Machine

Standard  specifications Of Full Automatic Unmanned Carton Bagging Machine:

Mechanical dimensions

L2400 × W1700 × H1850mm

Carton Size

(L200~600) × (W200-450)(H=H+W/2<550)mm

Inbound speed

22m/min (0-10 boxes/min)

Size of adhesive film

W220 ~ 600mm (M-type folding barrel membrane)

Film thickness

30~80um (M-type folding barrel membrane)

Conversion of carton adhesive film

Carton:(L+W)*2+160mm

Power Supply

220V/380V  50HZ

Table Height

<600mm

Mechanical length including leveling of bag in box

Standard machine length 1800mm

carton bagging machine

Non standard machine specification:

Mechanical dimensions

L2600 × W1800 × H2450mm

Carton Size

(L400~850) × (W300-550)(H=H+W/2<550-1100)mm

Inbound speed

22m/min (0-10 boxes/min)

Size of adhesive film

W400 ~ 850mm (M-type folding barrel membrane)

Film thickness

30~80um (M-type folding barrel membrane)

Conversion of carton adhesive film

Carton:(L+W)*2+160mm

Power Supply

220V/380V  50HZ

Table Height

<600mm

Mechanical length including leveling of bag in box

Standard machine length 1800mm

carton bagging machine


More information, please contact with me at any time!

Ady

Whatsapp:+86 15634865861

Full Automatic Unmanned Carton Bagging Machine
