Airport Using Luggage Wrapping Machines

Airport Using Luggage Wrapping Machines

Luggage packing machines (also known as Luggage wrapping machines) are specially designed to protect the safety of passengers' luggage during transportation.

Contact Now E-Mail Telephone WhatsApp

Product Details

Product introduction:

Airport Using Luggage Wrapping Machines /Baggage wrapping machine is designed to pack luggage, single cargo, small cargo, etc. in airports, stations, terminals, logistics points and other places. It can wrap the object in all directions to prevent the phenomenon of damage to baggage cargo, moisture-proof, dirt-proof, and being exchanged, so as to play a protective role in the transportation process. The equipment can be moved, the operator puts the item on the turntable, and adjusts the position of the vertical bar according to the size of the item, so that the item can be placed smoothly on the turntable. Then the operator presses the start button of the operation panel, the equipment automatically packs, automatically determines the height of the article, the number of packaging layers can be set to 1-9 layers, and the general item package can be 3-5 layers.

Main technology parameters of Luggage Wrapping Machine

Luggage Wrapping dimensions (LWH)	16106501200mm	1210600990mm	15506201730mm
Machine weight	220kg	200kg	220kg
Wrapping size (LWH)	(280-700)(280-420)(280-450)MM	(220-600)(220-450)(0-400)MM	(220-1000)(220-450)(300-900)MM
Load capacity	100kg	100kg	100kg
Power/Voltage	1P 220V 50HZ Other Voltage supplied	1P 220V 50HZ Other Voltage supplied	1P 220V 50HZ Other Voltage supplied
Surface treatment	Powder Coating	Baking varnish&Powder coating	Baking finished
Turntable speed	0-20rpm	0-36rpm	0-36rpm
Film carriage	No up&down	No up&down	Film can be Up&Down Big luggage & Small luggage separate
Film tension	Adjust from the control panel	Adjust from the control panel	Adjust from the control panel
Film for used	Film width:500mm thickness ≤0.035 Inner core:76.2mm Length:1600m Net weight:15kg Gross weight:16.4kg One side sticky Transparent or colored	Film width:500mm thickness ≤0.035 Inner core:76.2mm Length:1600m Net weight:15kg Gross weight:16.4kg One side sticky Transparent or colored	Film width:500mm thickness ≤0.035 Inner core:76.2mm Length:1600m Net weight:15kg Gross weight:16.4kg One side sticky Transparent or colored
Pre-stretch	250%-300%	250%-300%	250%-300%
Motor	Two motor. One:turntable One:film pre-stretch	Two motor. One:turntable One:film pre-stretch	Two motor. One:turntable One:film pre-stretch One:film up&down
Pack size (LWH)	17707651330	13407001120mm	L type :17507101780mm Rectangle:16807101010mm
Pack weight	240kg	220kg	240kg
Mark	Color can be select Foot pedal Scale(Weigh the luggage weight)	Color can be select Foot pedal Scale(Weigh the luggage weight)	Color can be select Foot pedal Scale(Weigh the luggage weight) Screen(Play the video) Battery(use out power) Camera Remote control

NOTE :

1. All the machine is packing in wooden case;

2. Delivery time: Within 30days after receiving 30% deposit payment by TT;

3. Payment: 30% deposit by TT, 70% balance by TT before delivery;

4. We can guide free to repair the machine all one’s life

5. Machine warranty:1 year. In one year, parts broken, free equipment supplied for main parts except quick-wear parts, not including air/sea freight too;

6. Documents for custom clearance: B/L,CI,PL,SALES CONTRACT,CO,CTN. For other documents, please inform advance.
