Fully Automatic Unmanned Shrink Packaging Machine Bagging Machine

The bagging machine, also known as shrink packaging machine, is a machine that wraps the product with heat shrinkable film and then heats it, so that the film shrinks and wraps the product.

Contact Now E-Mail Telephone WhatsApp

Product Details

Introduction of automatic bagging and packaging machine

Automatic bagging packaging machine, also known as shrink packaging machine, is usually a machine that wraps the product with heat shrinkable film and then heats it, so that the film shrinks and wraps the product. It uses heat shrinkable film in the heating state, the irregular arrangement between the original molecules has changed, under infrared and other heat radiation, plastic molecules are rearranged tightly, so that the original area is greatly reduced, and it is attached to the surface of the product to

achieve the purpose of packaging. During the shrinking process of the shrinking machine, it does not affect the quality of the packaging, but can shrink quickly and perfectly, and the packaged product can be sealed, moisture-proof, impact-proof, suitable for multiple items tightly packed and palletized.

Fully Automatic Unmanned Shrink Packaging Machine Bagging Machine

Automatic bagging machine main configuration description and features:

Standard bagging machine specifications:

Mechanical dimensions	L2400×W1700×H1850mm
Carton size	(L200～600)×（W200-450）(H=H+W/2<550)mm
Loading speed	22m/min (0-10 boxes/min)
Film size	W220~600mm(M type folding barrel film)
Film thickness	30~80um(M type folding barrel film)
Carton film conversion	Carton:（L+W）*2+160mm
power supply	220V/380V 50HZ
Table height	<600mm
The mechanical length includes the bag-in-box for flattening	Standard length 1800mm

Non-standard bagging machine specifications:

Mechanical dimensions	L2600×W1800×H2450mm
Carton size	(L400～850)×（W300-550）(H=H+W/2<550-1100)mm
Loading speed	22m/min (0-10 boxes/min)
Film size	W400~850mm(M type folding barrel film)
Film thickness	30~80um(M type folding barrel film)
Carton film conversion	Carton:（L+W）*2+160mm
power supply	220V/380V 50HZ
Table height	<600mm
The mechanical length includes the bag-in-box for flattening	Standard length 1800mm

Fully Automatic Unmanned Shrink Packaging Machine Bagging Machine

Main Configurations of Bagging Machine:

Configuration	Instruction	Brand origin
Control system	Using the latest PLC controller dedicated to stepper motor, it can still work stably under 24-hour overload work and power supply instability. (Mitsubishi).	Japan
Operation panel	Use "Weilun" man-machine interface, full Chinese display, just follow the instructions on the display screen, you can easily go online, electrostatic touch keyboard, large display LCD screen, no electromagnetic radiation, no copper foil oxidation trouble, low failure rate, long service life, adjustable backlight design, enhance display clarity.	Taiwan
Electric eye configuration	Whole line optoelectronics: "OMRON" "Panasonic"	Japan
Proximity switch	(Investigation range up to 10 turns, oilproof and waterproof, CE certification, no dead angle on the measurement label).	Japan
Drive controller	"OMRON" brand.	Taiwan
Servo motors	TECO brand: stable quality and easy adjustment.
Servo drives	"Mitsubishi" brand.	Taiwan
Relays	"Mitsubishi": stable quality, accurate positioning.
cylinder	"Omron" brand.	Japan
Motor/reducer	"SMC" brand.	Taiwan
Base (Machine)	"Shengbang" and "Liming" brand, stable quality, low noise, strong and durable, low power consumption.
Rack	"AUTOCAD" design, stable center of gravity, fixed feet and movable wheels.
Drum	Q235 carbon steel, sprayed with high-strength plastic steel powder on the outside and baked at 220 degrees, beautiful appearance, strong wear resistance and corrosion resistance.
Conveyor guardrails	Stainless steel material, strong and durable, beautiful appearance.
