Fully Automatic Through-type Laminating Film Machine

1. Machine Parameters For Fully Automatic Through-type Laminating Film Machine:

1.1 Equipment size: subject to actual design, layout drawing is for reference only

1.2 Total power: ≈1.5KW

1.3 Working voltage: 380 V, 50Hz, three-phase four-wire system

1.4 Air consumption: 1000ml/min

1.5 Pneumatic working pressure: 0.5~0.6Mpa

Air supply pressure: The pressure available in the user system is: 0.8 MPa

 Equipment demand pressure: not less than 0.5 MPa, otherwise equipment alarm stop, low voltage alarm device.

Device noise: ≤ 85dB(A)

All air sources (double or triple parts) output are equipped with quick exhaust devices, and one reserved interface is left at each single air source

1.6 pulling motor power: 0.37kw

1.7 lifting motor power: 0.75kw

2. Main performance Fully Automatic Through-type Laminating Film Machine:

2.1 Suitable pallet size: (1400×1200×1800)mm (including pallet)

2.2 Packing efficiency: 50-60 torr/h

2.3 Pulling speed: 9.5m/min

2.4 Pulling frame up and down moving speed: 4.5m/min

2.5 film breaking method: rodless cylinder drive, blade cutting film

2.6 The film roll of the laminator is above the ground, which is convenient for the upper and lower film rolls

2.7 The lamination is automatically cut off

3. Control system:

3.1 PLC programmable control, lamination width can be set;

3.2 Increase in lamination control system, add man-machine interface touch screen on the control cabinet.

3.3 Photoelectric switch, automatic sensing of the width of the goods;

3.4 The drive is chain driven, accurate positioning;

3.5 Frequency conversion speed regulation;

3.6 This machine is equipped with automatic and manual conversion functions, which better ensures the operation of the packaging system.

More requirements for Fully Automatic Through-type Laminating Film Machine, please contact with us at any time. We can customize the most suitable laminating film machine for you.
