Manmade Board Intelligent Packaging System Overview

The automatic packaging production line of this project is used to realize online detection and automatic packaging of finished boards sawn and cut by production line specifications.

The main functions of the automatic packaging line can meet the automatic circumferential wrapping, automatic topping guard, adding paper corner protection at the corner, and product long edge

Automatic packaging with short sides according to the predetermined program; The packing section and the sawing main line are linked, and the corresponding protection function is realized;

Contact Now E-Mail Telephone WhatsApp

Product Details

Process Of Manmade Board Intelligent Packaging System:

After the pallets enter the packing line in turn, the pallets are successively completed through chain transportation, including top lamination, automatic erection corner protection, automatic wrapping, automatic topping protection plate, and cushioning longitudinal and transverse strapping process, after the packaging is completed, the forklift passes the shipment, and the lifting chain conveyor transfers the pallet to the storage position


Basic parameters of Manmade Board Intelligent Packaging System:

1. Packaging: pallet (whole stack of wood-based panels)

2. Skids: wooden skids (can be made of waste slats)

3. Packing method: The packing position is shown in the figure below - 2 channels in the width direction. The length direction is played 4 channels, several channels are adjustable.

4. Pat standard: height 70mm * width 70mm * length * 1220-1830mm

5. Packaging weight: not more than 3500KG

6. Forward direction: Width direction forward

7. Processing cycle: 20-22 torr/hour (including pallet input and output time, continuous supply)

8. Packing belt, winding film, top film replacement time: <5 minutes/roll

Manmade Board Intelligent Packaging System

Other:

Applicable consumables:

1. Machine strapping:

1.1 Packing belt width 16~19mm

1.2 Packing belt thickness 0.8~1.0mm

1.3 Strapping material PET1.4 curl size: inner diameter 406mm, outer diameter 560mm, roll width 160_

2. Machine wrapping film:

2.1 Winding film type: PE mixed LDPE+ LLDPE

2.2 Winding film thickness: 17-23μm

2.3 core inner diameter: φ76mm

2.4 Width: 500mm

3. Paper corner protection:

3.1 Corrugated paper

3.290° right angle molded paper corner protection

Technical data of strapping machine:

Strap speed: 4.6 m/s Strapping force: 40-230 KG, adjustable welding head: friction welding ~ welding head length 30 mm using high-frequency friction broken belt, which can save costs, and facilitate belt replacement Strap width 16-19mm,

The success rate of strapping is 99%, and the deviation rate of 0-5mm equipment has the function of automatic padding. Number of pads: about 200 pieces.

The effect of Packaing:

Manmade Board Intelligent Packaging System
