Automatic Bag/Carton Folding Machine For Hot Sales

Automatic Bag/Cargon Folding Machine For Hot Sales

The action structure of automatic bag folding machine is mainly divided into two working areas, namely bag lifting, folding bag and bag pressing.

The box body is automatically entered into the machine through the conveyor line to complete the following station process.

1. Enter the bag carrying station and start the bag lifting action.

2. After entering the bag folding station, fold the bag in half from both sides, and flatten the folded bag into the box.

Contact Now E-Mail Telephone WhatsApp

Product Details

Automatic product carton positioning. Automatically lift the carton outward and inner bag after packing, and automatically press the carton into the carton by folding it in half in both directions. Realize automatic output for easy box sealing. Realize unmanned assembly line equipment, improve work efficiency, reduce labor, and improve customer production technology and automation. This machine adopts P.L.C+ display control, which greatly facilitates operation, management, reduces production personnel and labor intensity, and is an indispensable equipment for automated large-scale production. Easy to operate, reduce packaging costs.

Main mechanism: using servo motor control system, accurate and fast.

Native features of Carton Folding Machine:

Automatic Bag Folding Machine For Hot Sales

This machine should be used with automatic bagging machine:

Inner carton size: need to confirm

Carton size: need to confirm

Table height: 600mm

Applicable power supply: 220v 4.5KW

Air pressure source supply: 6KG/cm2

Main technical parameters:

MACHINE SIZE:2700L*1800W*2000H(Vertical)

Packing speed: 1-5 cartons per minute

Power supply: 220/50/60Hz

Model	SZD-01
Mechanical dimensions	2700×2190×2100mm
Carton size	L690W520H248mm L640W450H300mm
Loading speed	12m/min (1-5pcs/min)
Sealing method	not
power supply	220V 50/60HZ
Air pressure source	5Kg/cm2

Main Configurations of Bag Folding Machine:

disposition	Instruction	Brand or origin
Control system	Using the latest PLC controller dedicated to stepper motor, it can still work stably under 24-hour overload work and power supply instability.	Siemens
Operation panel	Use "Weilun" man-machine interface, full Chinese display, just follow the instructions on the display screen, you can easily go online, electrostatic touch keyboard, large display LCD screen, no electromagnetic radiation, no copper foil oxidation trouble, low failure rate, long service life, adjustable backlight design, enhance display clarity.	Siemens
Photoelectric switch	Whole line optoelectronics: "OMRON" "Panasonic"	Japan
Proximity switch	(Investigation range up to 10 turns, oilproof and waterproof, CE certification, no dead angle on the measurement label).	Japan
Drive controller	"OMRON" brand.	Taiwan
Servo motors	TECO brand: stable quality and easy adjustment.
Servo drives	"Mitsubishi" brand.	Taiwan
Relays	"Mitsubishi": stable quality, accurate positioning.
cylinder	"Omron" brand.	Japan
Motor/reducer	"SMC" brand.	Taiwan
Base (Machine)	"Shengbang" and "Liming" brand, stable quality, low noise, strong and durable, low power consumption.
Rack	"AUTOCAD" design, stable center of gravity, fixed feet and movable wheels.
Drum	Q235 carbon steel, sprayed with high-strength plastic steel powder on the outside and baked at 220 degrees, beautiful appearance, strong wear resistance and corrosion resistance.
Conveyor guardrails	Stainless steel material, strong and durable, beautiful appearance.
