Clip Type Automatically Adding Wooden Block And Small Corner Strapping Machine

Clip type automatically adding wooden block automatically adding small corner strapping machine

Quantity: 1 set

Function: Using the original imported packing head, the panel stack is automatically bundled with a wide edge and automatically added a small corner protector

Function description:

The wide edge of the wood-based panel to be packaged is bundled, and the cushion block is packed to the bottom of the wood-based panel to be packaged, and the number of binding lanes in the wide direction can be set, and the small corner protection is automatically added

Contact Now E-Mail Telephone WhatsApp

Product Details

Strapping Machine technical requirements and component formulation

Remarks:

Packing frame size

Passable height: up to 1400 mm

Width that can be passed: up to 2100 mm

Drive method: Driven by a stepless variable speed motor

Applicable power supply: 380V

Production speed: 2 bundles not less than 25 torr/h

Load capacity: 4000kg

Strapping Machine

Strapping Machine requirements

The strapping tightness is adjustable, PET strapping is used, and the movement is positioned at the top.

The strapping speed ≥ 25 tors/hour, and the strapping pass rate ≥99%.

After packing, the strapping strapping slope is ≤ 30mm, and the strapping belt is straight and without ripple after packing.

The maximum adhesion force of PET tape after packaging is not less than 80% of the tensile breaking force of PET strapping.

After packing, the center offset of the upper and lower strapping belt joints is not more than 1mm; The length of the strapping belt must not exceed 20mm if the end of the strapping joint is not attached.

The automatic baler also has a "manual" mode, and the manual and automatic switching is simple and smooth.

The automatic packaging machine has a counting function, the system can record the packaging situation of not less than one month, and can query the number of packages according to the time period; Pack counts can be read using a storage device for later storage.

Automatic shutdown function of conveyor line: electric eye starts the conveyor line, and after the stack body is sent, the conveyor line automatically stops, saving the cost of use and improving the life of the machine.

The equipment has a "pass" function, when the whole wheel hub does not need to be packed, the equipment is put into the "pass" function state, the whole wheel hub is directly and automatically output directly to the next station through the packing station, and the turntable and strapping machine have no action.

Equipment description: (including: for the realization of vertical packaging, packaging process control system control mode, specific packaging cycle time, etc.)

Strapping Machine

Assorted:

1) Automatic small corner protection machine (2 sets):

1. The mechanism can automatically detect and adjust the installation position (the center of the workpiece and the rotation center of the winding machine basically coincide).

2. It can detect the margin of paper corner protection and realize automatic warning, and then manually supplement the paper corner protection.

3. After the paper corner protection is placed, the two surfaces adjacent to the workpiece edge are aligned without gaps, and there is no skew phenomenon.

4. 2 paper corner protectors are installed and installed vertically, subject to the schematic diagram provided by the demander.

5. The whole process of placing paper corner protection realizes unmanned operation, and the equipment is in operation.

6. The demander provides the specifications of the paper corner protection for confirmation, and the bottom surface is used as the reference when placing the paper corner protection.

7. Servo motor control, more accurate

8. Corner protection machine corner protection specifications: 80mm×80mm×5mm small cardboard (cost saving)

Assorted:

1) Palletizing pad loading freighter device (1 set):

It is used in conjunction with strapping machine plus pad block flattening corner protection machine

Pad block placement, disposable forklift stacking not less than 100, not less than 1 hour dosage, greatly reduce the labor intensity of the pad block, save labor

Requirements: the mat side does not have a pallet, the forklift fork is taken to the position of the gasket, and then the strapping belt is cut off, the manual placement rules, the strapping belt is bundled, and then through the pad-block pusher, according to the system instructions, according to the needs of different positions of the pads placed work, stable and efficient, greatly reducing the space occupied by the padding machine.
